Designer
File Type
- Product line drawings in .DWG
- Install instructions in .PDF
- Photometry files in .IES and photometry reports in .PDF
- Revit/Revit Family files in .RFA
- 3D models in .SKP
IP RatingIngress Protection rates the degree of protection against dust and water.
- Basic luminaire construction.
ComplianceSafety certifications and regulations for our catalog of luminaires.
- Wall-mounted luminaires protruding up to 4" from the wall.
- Luminaires that have been tested by UL to nationally recognized safety and sustainability standards.
Input Voltage
- 100-120V. Input power most commonly used in North, Central America, and Japan.
- 110-277V. Universal input power for global applications. Often requires additional control wires for dimming.
Dimming ControlDimming control options for our catalog of luminaires.
- 0-10V is commonly used in high performance requirements such as commercial projects. It requires analog control wires that send signals from 0 to 10 volts to determine dim level. Excellent performance.
- Also known as TRIAC It’s the most commonly installed dimming control system that operates on 120V AC. Works with most common household dimmer switches. Additional control/signal wires not required.
